Showing 10–18 of 185 results
AMICO LXSG 25mm
Specification Amico 25mm
- Size : 25mm ( 1 inch)
- Max Flow Rate (Qmax) : 7 M3/h
- Nominal Flow Rate (Qn) : 3.5 M3/h
- Transitional Flow Rate (Qt) : 0.28 M3/h
- Minimum Flow Rate (Qmin) : 0.07 M3/h
- Working Pressure : 10 BAR
- Starting Flow Rate : 0.020 M3/h
- Accuracy : 2%
AMICO LXSG 32mm
Specification Amico 32mm
- Size : 32mm ( 1 1/4 inch)
- Max Flow Rate (Qmax) : 12 M3/h
- Nominal Flow Rate (Qn) : 6 M3/h
- Transitional Flow Rate (Qt) : 0.48 M3/h
- Minimum Flow Rate (Qmin) : 0.12 M3/h
- Working Pressure : 10 BAR
- Starting Flow Rate : 0.020 M3/h
- Accuracy : 2%
AMICO LXSG 40mm
Specification Amico 40mm
- Size : 32mm ( 1 1/2 inch)
- Max Flow Rate (Qmax) : 20 M3/h
- Nominal Flow Rate (Qn) : 10 M3/h
- Transitional Flow Rate (Qt) : 0.8 M3/h
- Minimum Flow Rate (Qmin) : 0.2 M3/h
- Working Pressure : 10 BAR
- Starting Flow Rate : 0.050 M3/h
- Accuracy : 2%
AMICO LXSG 50mm
Specification Amico 50mm
- Size : 50mm ( 2 inch)
- Max Flow Rate (Qmax) : 30 M3/h
- Nominal Flow Rate (Qn) : 15 M3/h
- Transitional Flow Rate (Qt) : 3 M3/h
- Minimum Flow Rate (Qmin) : 0.45 M3/h
- Working Pressure : 10 BAR
- Starting Flow Rate : 0.050 M3/h
- Accuracy : 2%
Aqua Metro Contoil Type VZO 15
Specification Aquametro Contoil Type VZO 15
- Nominal Diameter = 15 mm (1/2 inch)
- Installation length = 165 mm
- Nominal pressure = 16 bar (with threaded ends) 25-40 bar (with flanges)
- Max temperature = 130, 180 C
- Max flow rate = 600 L/H
- Nominal flow rate = 400 L/H
- Minimal flow rate = 10 L/H
- Approx. Starting flow rate = 4 L/H
- Max. Permissible error = + 1 % of actual value
- Repeatability = + 0.2 %
- Safety filter mesh size = 0.400 mm
- Dirt filter mesh size = 0.250 mm
- Volume of the measuring chamber = 12 approx.cm3
- Housing finish = enamelled red RAL 3013
- Smallest readable amount = 0.01 L
- Regisration capacity = 1000 m3
- Registration time at Qcont until overrunning to zerp = 2500 H
- Pulse frequency IN at Qmax = 16.667 Hz
- Pulse frequency IN at Qmin = 0.278 Hz
Aqua Metro Contoil Type VZO 20
Specification Aquametro Contoil Type VZO 20
- Nominal Diameter = 20 mm (3/4 inch)
- Installation length = 165 mm
- Nominal pressure = 16 bar (with threaded ends) 25-40 bar (with flanges)
- Max temperature = 130, 180 C
- Max flow rate = 1500 L/H
- Nominal flow rate = 1000 L/H
- Minimal flow rate = 30 L/H
- Approx. Starting flow rate = 12 L/H
- Max. Permissible error = + 1 % of actual value
- Repeatability = + 0.2 %
- Safety filter mesh size = 0.400 mm
- Dirt filter mesh size = 0.400 mm
- Volume of the measuring chamber = 36 approx.cm3
- Housing finish = enamelled red RAL 3013
- Smallest readable amount = 0.01 L
- Regisration capacity = 10000 m3
- Registration time at Qcont until overrunning to zerp = 10000 H
- Pulse frequency IN at Qmax = 41.667 Hz
- Pulse frequency IN at Qmin = 0..833 Hz
Aqua Metro Contoil Type VZO 25
Specification Aquametro Contoil Type VZO 25
- Nominal Diameter = 25 mm (1 inch)
- Installation length = 190 mm
- Nominal pressure = 16 bar (with threaded ends) 25-40 bar (with flanges)
- Max temperature = 130, 180 C
- Max flow rate = 3000 L/H
- Nominal flow rate = 2000 L/H
- Minimal flow rate = 75 L/H
- Approx. Starting flow rate = 30 L/H
- Max. Permissible error = + 1 % of actual value
- Repeatability = + 0.2 %
- Safety filter mesh size = 0.400 mm
- Dirt filter mesh size = 0.400 mm
- Volume of the measuring chamber = 100 approx.cm3
- Housing finish = enamelled red RAL 3013
- Smallest readable amount = 0.01 L
- Regisration capacity = 10000 m3
- Registration time at Qcont until overrunning to zerp = 5000 H
- Pulse frequency IN at Qmax = 8.333 Hz
- Pulse frequency IN at Qmin = 0..208 Hz
Hubungi kami untuk informasi Harga dan ketersediaan Produk
